2 bay ARM 4C 2.0GHz ; 2 x SATA 6Gb/s 3.5"/2.5"; 2GB RAM on-board; 1 x GbE ; 1 x USB3.2 Gen1 and 2 x USB2.0
Maunfacturer Warranty: 2 Years Maunfacturer Warranty
CPU | ARM 4-core Cortex-A55 2.0GHz processor |
CPU Architecture | 64-bit ARM |
Floating Point Unit | |
Encryption Engine | |
System Memory | 2 GB, not expandable
Note: Reserves some RAM for use as shared graphics memory. |
Maximum Memory | 2 GB, not expandable |
Flash Memory | 4 GB (Dual boot OS protection) |
Drive Bay | 2 x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility | 3.5-inch SATA hard disk drives 2.5-inch SATA hard disk drives 2.5-inch SATA solid state drives |
Hot-swappable | |
Gigabit Ethernet Port (RJ45) | 1 |
Wake on LAN (WOL) | |
Jumbo Frame | |
USB 2.0 port | 2 |
USB 3.2 Gen 1 port | 1 |
Form Factor | Tower |
LED Indicators | System Status, LAN, USB, HDD1~2 |
Buttons | Power, Reset, USB Copy |
Dimensions (HxWxD) | 188.64 × 90.18 × 156.26 mm |
Weight (Net) | 1.11 kg |
Weight (Gross) | 1.95 kg |
Operating temperature | 0 - 40 °C (32°F - 104°F) |
Storage Temperature | -20 - 70°C (-4°F - 158°F) |
Relative Humidity | 5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit | 65W adapter (12VDC), 100-240VAC |
Power Consumption: HDD Sleep Mode | 3.43 W |
Power Consumption: Operating Mode, Typical | 10.81 W
Tested with drives fully populated. |
Fan | 1 x 80mm, 12VDC |
System Warning | Buzzer |
Max. Number of Concurrent Connections (CIFS) - with Max. Memory | 200 |
SKU | TS-233 |
Barcode # | 885022022946 |
Brand | QNAP |
Shipping Weight | 2.0000kg |
Shipping Width | 0.260m |
Shipping Height | 0.130m |
Shipping Length | 0.320m |
